The Cooler Master HAF 500 Mid Tower Case in Black combines aggressive styling with practical engineering for demanding PC builds. This chassis features a front-mounted 200mm fan and rear 120mm exhaust configuration, delivering efficient thermal management for high-performance systems. The mesh front panel maximizes airflow while filtering dust, protecting internal components during extended operation. Tempered glass side panel showcases your hardware with clarity and durability. The interior layout supports graphics cards up to 370mm and CPU coolers reaching 160mm in height, accommodating modern high-end components without compromise. Tool-free expansion slots and simplified cable management pathways reduce assembly time and improve organization. The robust steel construction provides structural integrity while maintaining a compact mid-tower footprint suitable for both gaming and professional workstations. Designed for builders prioritizing cooling performance and component visibility.
Brand : Cooler Master
Color : Black
| Model No | Cooler Master HAF 500 Mid Tower Steel Plastic Tempered Glass Panel Case with 3 ARGB Fans - Black |
| Part No | H500-KGNN-S00 |
| Color | Black |
| Case Material | Steel, Mesh, Plastic |
| Case Size | 516 x 224 x 510mm (incl. Protrusions) |
| Lighting | RGB |
| Motherboard Support | ITX, M-ATX, ATX, SSI CEB, E-ATX* (*up to 12"x14.1", may impact cable management and case features) |
| Pre-installed Fans | Pre-installed Fans - Front 2x 200mm ARGB Fan Pre-installed Fans - Rear 1x 120mm SickleFlow PWM ARGB Pre-installed Fans - Top on HDD cage 1x 120mm SickleFlow PWM |
| Additional Fan Support | Fan Support - Top 3x 120mm / 2x 140mm / 2x 200mm Fan Support - Front 3x 120mm / 2x 140mm / 2x 200mm (*200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness) Fan Support - Rear 1x 120mm Fan Support - Top on HDD cage 1x 120mm |
| Radiator Support | Radiator Support - Top 120 / 140 / 240 / 280 / 360mm Radiator Support - Front 120 / 140 / 200 / 240 / 280 / 360mm Radiator Support - Rear 120mm |
| SSD/HDD Support | 7 Slots Behind MB Tray: 2 X 2.5″ SSD Hard Drive Cage: 3 X 3.5″ HDD/2.5″ SSD Behind the Right-side Shroud Panel: 2 X 2.5″ SSD |
| I/O Ports | I/O Panel - USB Ports 2x USB 3.2 Gen 1 (USB 3.0), 1x USB 3.2 Gen 2 type C I/O Panel - Audio In / Out 1x single Audio jack I/O Panel - Other 1x ARGB Hub |
| CPU Cooler Limitation | 167mm/6.5" |
| VGA Limitation | 410mm/16.1" |
| PSU Limitation | 180mm/7.1" |
| Dust Filters | Top, Bottom |
| Product Size ( Dimension ) | 516 x 224 x 510mm (incl. Protrusions) |
| Package Content | Case & Cables |
| Warranty | 1 Year ( As per Manufacturer Policy ) |
