Cooler Master Mwe 1250W V2 80 Plus Gold Fully Modular - Black

High Temperature Resilience

MWE Gold V2 1250 series is able to push its temperature resilience to 50 degree Celsius safely. Such a high threshold greatly improves what's possible to accomplish with the unit and your system in general. Overclocking and other high intensity applications become way more accessible when the system's power supply unit can take the heat.

Full Modular Cabling

MWE Gold V2 1250 comes with flat black cables that can be customized to each user's individual needs. The flat cable design also benefits the overall cable management and improves airflow. MWE Gold V2 1250 also provides enough connectors for the system with the latest motherboards and RTX graphics cards.

PSU Calculator

Need help choosing the right power supply for your system? Try out our easy to use, comprehensive PSU calculator.

Specifications

• Model : MPE-C501-AFCAG

• ATX Version  : ATX 12V V2.52

• PFC  : Active PFC

• Input Voltage : 100-240V

• Input Current : 15-7A

• Input Frequency  : 47-63Hz

• Dimensions (L x W x H)  : 180 x 150 x 86 mm

• Fan Size  : 140mm

• Fan Bearing  : FDB

• Fan Speed  : 2200 RPM

• Noise Level @ 20%  : 0 dBA

• Noise Level @ 50%  : 15.8 dBA

• Noise Level @ 100%  : 30.1 dBA

• Efficiency  : ≥90% @ Typical Load

• 80 PLUS Rating  : 80 PLUS Gold

• ErP 2014 Lot 3  : Yes

• Operating Temperature  : 0-50 °C

• Power Good Signal  : 100 - 150 ms

• Hold Up Time  : >20ms at 100% Load

• MTBF  : >100,000 Hours

• Protections  : OVP, UVP, OPP, OTP, SCP, OCP

• Regulatory  : TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA

• ATX 24 Pin Connectors  : 1

• EPS 4+4 Pin Connectors : 1

• EPS 8 Pin Connector  : 1

• SATA Connectors  : 12

• Peripheral 4 Pin Connectors  : 4

• PCI-e 6+2 Pin Connectors  : 8

• Series     MWE Gold Series

• 80 Plus  : Gold

• Modular  : Full Modular

• Wattage  : Above 750W
