The Cooler Master Qube 500 Flatpack EATX Case in Macaron delivers full-tower capability with distinctive aesthetic appeal for builders seeking visual differentiation. This expansive chassis accommodates extended ATX, standard ATX, Micro-ATX, and Mini-ITX motherboards, supporting dual-socket server configurations and graphics cards exceeding 400mm in length. The innovative flatpack construction minimizes shipping dimensions while maintaining exceptional structural integrity, reducing logistics overhead without compromising durability or build quality. Extensive fan mounting architecture supports 120mm and 140mm units across multiple positions, enabling sophisticated thermal management strategies for extreme overclocking, water-cooling loops, and sustained professional workloads. The spacious interior facilitates unrestricted component placement and cable routing, critical for modular power supplies and complex custom cooling implementations.
| Model Number | Q500-DGNN-S00 |
| Exterior Color | 3x set: Mint, Pink, Cream |
| Materials - Exterior | Steel, Plastic, TG |
| Materials - Left Side Panel | Grey TG + Steel |
| Dimensions (L x W x H) | 406 x 231 x 415mm (Incl. Protrusions); 380 x 231 x 381mm (Excl. Protrusions) |
| Volume | 33.44L (Excl. Protrusions) |
| Motherboard Support | ITX, Micro ATX, ATX, E-ATX (Width up to 296mm w/ SFX PSU; up to 273mm w/ ATX PSU) |
| Expansion Slots | 7 |
| 3.5" Drive Bays | Max. 4x 3.5" HDD |
| 2.5" Drive Bays | Max. 3x 2.5" SSD |
| I/O Panel - USB Ports | 2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2 x 2 Type C |
| I/O Panel - Audio In / Out | 1x 3.5mm Combo |
| Pre-installed Fans - Rear | 1x 120mm (1800 RPM) SF ARGB White PWM |
| Fan Support - Front | 1x 120/140mm (x2 if PSU is mounted in bottom) |
| Fan Support - Top | 2x 120/140mm |
| Fan Support - Rear | 1x 120mm |
| Fan Support - Bottom | 2x 120/140mm |
| Fan Support - Left Side | 2x 120/140mm |
| Radiator Support - Front | 120/140mm (240/280mm w/ PSU in bottom) |
| Radiator Support - Top | 120/140/240/280mm (280mm can be used within 53mm thickness) |
| Radiator Support - Rear | 120mm |
| Radiator Support - Bottom | 120/140/240/280mm |
| Radiator Support - Left Side | 120/140/240/280mm |
| Clearance - CPU Cooler | 164mm-172mm (Remove the water cooling bracket) |
| Clearance - PSU | 173mm to first GPU slot, 216mm max (w/o cable management); 332mm (mounted in bottom) |
| Clearance - GFX | 365mm |
| Cable Routing - Behind MB Tray | 29-32mm |
| Handle | Mint x 1, Grey x 1 |
| Gem Mini | Grey x 1 |
| Accessory Hook | x2 |
| Dust Filters | Front, Top, Bottom, Right Side |
| Power Supply Support | SFX, SFX-L, ATX |
| Size | Mid Tower |
| Series | QUBE Series |
| Back Connector MB Support | No |
