Protocol | CSMA/CD | |
Data Transfer Rates | Ethernet: 10 Mbps (half duplex) 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex) 200 Mbps (full duplex) |
|
Topology | Star | |
Network Cables | 10BASE-T: UTP CAT 3, 4, 5/5e (100 m max. EIA/TIA-586 100-ohm STP (100 m max.) 100BASE-TX, 1000BASE-T: UTP CAT 5/5e (100 m max.) EIA/TIA-568 100-ohm STP (100 m max.) |
|
Media Interface Exchange | Auto MDI/MDIX adjustment for all ports | |
LED Indicators | Per port: Link/Activity/Speed Per device: Power |
|
Transmission Method | Store-and-forward | |
MAC Address Table | 8K entries per device | |
MAC Address Learning | Automatic update | |
Packet Filtering/Forwarding Rates | Ethernet: 14,880 pps per port Fast Ethernet: 148,800 pps per port |
|
RAM Buffer | 256 KBytes per device | |
DC Input | Switching 5 V / 1 A Level “V” Power Adapter | |
Power Consumption | Power On (Standby): AC input: 2.36 watts DC input: 1.2 watts Maximum: AC input: 2.69 watts DC input: 1.6 watts |
|
Operating Temperature | 0 to 40 ˚C (32 to 104 ˚F) | |
Storage Temperature | -10 to 70 ˚C (14 to 158 ˚F) | |
Operating Humidity | 10% to 90% RH non-condensing | |
Storage Humidity | 5% to 90% RH non-condensing | |
Device Dimensions (W x D x H) | 155.7 x 122 x 41 mm (6.13 x 4.80 x 1.61 inches) | |
Certifications | CE Class B FCC class B CB RoHS EuP |
