1000Base-T PoE Interface | 24 |
---|---|
Combo 1000Base-T/SFP | 4 |
Auto MDI/MDIX | Yes |
10/100/1000BASE-T PoE ports | 24 |
Combo 10/100/1000BASE-T/SFP ports | 4 |
Switch Capacity | 56 Gbps |
Max. Packet Forwarding Rate | 41.7 Mpps |
Store & Forwarding Forwading | Yes |
Dimension | 440mm x 250 mm x 44mm |
Weight | 3.94 kg |
Operation Temperature | -5 - 50°C |
Storage Temperature | -20-70°C |
Operation Humidity | 0% - 95% RH |
Storage Humidity | 0% ~ 95% RH |
Operating Altitude | 1500 meters |
Maximum Power Consumption | PoE on 446.1 W/100 V 424.8 W/240 V PoE off 29.8 W/100 V 29.0 W/240 V |
Standby Power Consumption | 18.5 W/100V / 17.1 W/240V |
Maximum Heat Dissipation | 1521.99 BTU/hr (100 V) 1449.49 BTU/hr (240 V) |
MTBF | 277,967 hours |
Power Input | 100-240 VAC |
CPU Speed | 500MHz |
Flash Memory Size | 32MB |
Packet Buffer Size | 4.1MBits |
DRAM Size | DDR3 128MB |
FAN | Yes |
Comply with RoHS 6 | Yes |
Energy Efficiency Ethernet (EEE) | Yes |
Power Saving By Link Status | Yes |
Power Saving By Cable Length | Yes |
Power Saving By Port Shut-Off | Yes |
Power Saving By System Hibernation | Yes |
Time-based PoE | Yes |
Maximum PoE Budget | 370W |
PoE Budget | 370 W |
