The NZXT F120 RGB Duo represents a sophisticated cooling solution engineered for high-performance PC builds. This triple pack delivers three 120mm fans, each featuring dual-sided RGB lighting that creates immersive visual effects throughout your case. The fans utilize optimized blade geometry to balance airflow efficiency with minimal noise generation, making them ideal for both air cooling and radiator applications. With synchronized RGB control via NZXT's CAM software, you can customize lighting patterns to match your system aesthetics. The black finish complements modern case designs while the robust bearing construction ensures reliable long-term operation. Whether you're building a gaming rig or workstation, these fans provide the performance and visual appeal demanded by discerning enthusiasts.
| Specification | Details |
|---|---|
| Key Feature – RGB Lighting | 20 individually addressable LEDs visible from all angles |
| Key Feature – Fan Blade Design | Balanced for high airflow and high static pressure |
| Key Feature – Bearing Type | Fluid Dynamic Bearing (FDB) ensures smooth, quiet operation |
| Key Feature – Noise Reduction | Rubber dampeners reduce vibration noise |
| Key Feature – PWM Control | Efficient cooling at high load, quiet at low load |
| Key Feature – Compatibility | Works with NZXT F120/F140 RGB fans |
| Key Feature – CAM Support | Lighting & fan customization via NZXT CAM |
| Key Feature – Dual-Sided Lighting | RGB lighting visible from every angle |
| Key Feature – RGB Controller Support | Customize lighting via NZXT RGB Controller |
| Material | Plastic, rubber, PCB |
| Fan Rated Voltage | 12V DC, 0.13A, 1.56W |
| LED Quantity | 20 |
| Bearing Type | Fluid Dynamic Bearing (FDB) |
| Fan Connector | 4-pin PWM |
| Fan Height | 120 mm |
| Fan Width | 120 mm |
| Fan Depth | 25 mm |
| Fan Speed | 500 – 1,800 ± 300 RPM |
| Airflow | 50.00 CFM |
| Static Pressure | 2.60 mm-H₂O |
| Noise Level | 31.0 dBA |
| Fan Life (Hours) | 60,000 |
| Fan Life (Years) | 6 |
| RGB Controller Dimensions | 63.2 × 53.2 × 12.8 mm |
| RGB Controller Weight | 52.8 g |
| RGB Controller Materials | Plastic, PCB, magnets |
| RGB Controller Mounting | 2× 3M Dual Lock |
| RGB Controller Connections | 1 × USB 2.0 header, 1 × SATA |
| RGB Controller Input | 12V DC / 2.6A |
| Output Channel Voltage | 5V DC |
| RGB Lighting Channels | 3 |
| LED Support | Up to 40 LEDs per channel / 120 total |
| System Requirement – PC | Requires NZXT RGB lighting connector |
| System Requirement – OS | Windows 10 or Windows 11 |
| System Requirement – Internal Connector | Requires USB 2.0 internal connector |
