The NZXT H5 Flow (2024) represents a refined approach to compact mid-tower design, delivering professional-grade cable management and thermal performance in a space-conscious form factor. This white chassis accommodates full-size ATX motherboards while maintaining a footprint ideal for desk setups and smaller builds. The front mesh panel optimizes airflow to CPU and GPU components, while the integrated cable routing system behind the motherboard tray keeps your build organized and visually clean. Tempered glass side panel provides clear visibility of your components, and the modular interior layout supports multiple storage configurations. Whether you're building a high-performance workstation or a content creation rig, the H5 Flow balances functionality with aesthetic appeal, making it a versatile choice for builders who demand both capability and restraint in their case selection.
|
Model No |
NZXT H5 Flow (2024) Compact Mid-Tower ATX Case - White |
|
Part No |
CC-H52FW-01 |
|
Color |
White |
|
Motherboard Support |
ATX, E-ATX, Micro-ATX, Mini-ITX |
|
External Drive Bays |
No |
|
Internal Drive Bays |
2x 2.5" and 1x 3.5" |
|
Expansion Slots |
7x Full Height |
|
Maximum GPU Length |
16.1" / 410 mm |
|
CPU Cooler Height |
6.9" / 175 mm |
|
Supported PSU Size |
ATX |
|
Maximum PSU Length |
7.9" / 200 mm |
|
PSU Mounting Location |
Bottom |
|
Fan Mounting |
Front 3x 120 mm or 2x 140 mm Top 2x 120/140 mm Bottom 2x 120 mm Rear 1x 120 mm |
|
Fans Included |
Front: 1x 120 mm Non-LED (1350 rpm) Rear: 1x 120 mm Non-LED (1350 rpm) |
|
Maximum Radiator Size |
Front: 360 mm Top: 240 mm |
|
Noise Level |
24.1 dBA |
|
Fan Controller Included |
No |
|
Filter Locations |
Bottom, Front, Top |
|
I/O |
1x USB-A (USB 3.0 / 3.1/3.2 Gen 1) 1x USB-C (USB 3.0 / 3.1/3.2 Gen 1) |
|
Media/Memory Card Slot |
No |
|
Audio I/O |
1x 3.5 mm Input/Output |
|
Display Outputs |
No |
|
Windowed Panel |
Yes |
|
Color |
White |
|
Material |
Steel, Tempered Glass |
|
Certifications |
No |
|
Built-In Lighting |
No |
|
Tool-Less Design |
Thumbscrews |
|
Security |
No |
|
Cable Management Space |
1.1" / 28.7 mm |
|
Dimensions (W x H x D) |
16.9 x 18.3 x 8.9" / 430 x 465 x 225 mm |
|
Weight |
15.72 lb / 7.13 kg |
|
Package Weight |
20 lb |
|
Box Dimensions (LxWxH) |
22 x 20.75 x 12.25" |
