Vendor: Tenda
SKU: TEG5310P-8-150W
Product type: Poe Switches
37.000 KD
42.500 KD
37.000 KD
Description

Enterprise-grade network management meets reliable power delivery with the TENDA 8 PORT L3 Managed PoE Switch. Designed for professional installations, this switch delivers intelligent Layer 3 routing capabilities alongside integrated Power over Ethernet functionality, enabling you to power and connect devices through a single cable. The 8-port configuration provides flexible connectivity for mid-scale deployments, while managed features grant full control over network traffic, VLAN configuration, and device prioritization. Built for stability and performance, this switch supports high-speed data transmission with efficient power distribution to IP cameras, access points, and other PoE-compatible equipment. Ideal for businesses seeking centralized network control without the complexity of separate power infrastructure, the TENDA L3 Managed PoE Switch streamlines installation and reduces cabling costs across your facility.

Specifications

Model No

TENDA 8 PORT L3 Managed PoE Switch

Part No

TEG5310P-8-150W

Color

Brown

Network standards

IEEE802.3、 IEEE802.3u、 IEEE802.3ab、 IEEE802.3z、 IEEE802.3x、 IEEE802.3af/at、 IEEE802.1p、IEEE802.1q、 IEEE802.1w、 IEEE802.1d、 IEEE802.1s

LED Indicator

1*Link/Act or PoE LED indicator

1*Link/1*Link/Act mode converting LED indicator

1*PoE mode converting LED indicator

1*PoE Max LED indicator

1*Power LED indicator

1*SYS LED indicator

Interfaces

8*10/100/1000 Base-T Ethernet ports (Data/Power)

1*10/100/1000 Base-T Ethernet ports (Data)

1*1000 Base-X SFP ports (Data)

Transmission media

Recommended: CAT5/5e UTP or better

Level of protection

Lightning protection for ports: 6kV

Lightning protection for power: 6kV

ESD:

Air discharge: ±10kV

Contact discharge: ±8kV

Forwarding mode

Store-and-forward

Switch capacity

20Gbps

Packet forwarding rate

14.90Mpps

Buffer

12Mb

MAC address table

16K

Jumbo frame

10K

PoE power supply management

Support

PoE budget

Single port: AF: 15.4W, AT: 30W

Whole device: 130W

Input voltage

100-240V AC 50/60Hz

Power consumption

Full load: ＜160W

Empty load: ＜12W

Dimension

294.0mmx179.6mmx44.0mm

Mounting

Desktop mounting: support

Wall mounting: support

Rack mounting:non-support

Energy Efficient

Support

Environment

Operating temperature: 0°C - 45℃

Storage temperature: -40°C - 70°C

Operating humidity: (10% - 90%) RH, non-condensing

Storage humidity: (5% - 90%) RH, non-condensing

Certification

FCC、CE、RoHS

L3 Features

VLAN-based routing

IPv4 static routing adding

Static ARP adding/deleting

ARP aging time configuration

PoE power supply management

Supports port PoE configuration and power supply with priority

Supports PoE over-temperature protection

Supports PoE scheduled management

Supports intelligent management and PoE-powered device detection

(port status, power assignment and PoE-powered device status)

Security features

ARP receiving limit

Unknown MAC address discard

DoS attack defense

802.1x security authentication

Radius security authentication

VLAN

IEEE 802.1Q VLAN

VLAN Layer-3 interfaces

Supports three port modes: Access, Trunk and Hybrid

DHCP Server

DHCP Server

DHCP Relay

DHCP Snooping

Supports Option 82 policy configuration

Port aggregation

Static aggregation

LACP dynamic aggregation

Spanning tree

IEEE 802.1d STP (Spanning Tree Protocol)

IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)

IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)

Supports edge port

Supports BPDU statistics

Multicast

IGMP Snooping V1/V2/V3

Supports port fast leave

Port Mirroring

Supports N: 1 port mirroring

Quality of Service

SP (Strict Priority)

SWRR (Simple Weighted Round Robin)

WRR (Weighted Round Robin)

Supports 802.1p port trust mode

Supports DSCP port trust mode

Supports a maximum of 8-queue service quality mapping

ACL

Supports MAC ACL and IP ACL

Loading and upgrade

Supports FTP/TFTP/HTTP upgrade

Supports configuration import and export

Management and maintenance

Supports Telnet

Supports SNMP V1/V2/V3

Supports WEB management and maintenance

Supports Ping/Tracert/Connection Detection

CPU Monitoring and memory monitoring

Local visualization management

Warranty

1Year (As Per Manufacturer)
