When a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The TL-SG1024D can automatically detect the link status of each port and reduce the power consumption of ports that are idle. Ideally, shorter cables would use less power because of less power degradation over their length; this is not the case with most devices as they will use the same amount of power across the cable regardless of whether it is 10 or 50 meters (32.8 or 164.0 feet )in length. The TL-SG1024D analyzes the length of the Ethernet cable connected and adjusts the power usage accordingly, rather than keeping the power consumption in a conventional solution.
Brand | TP-Link |
Model Number | TL-SG1024D |
Number Of Ports | 24 Port |
Color | Black |
HARDWARE FEATURES | Standards and Protocols- IEEE 802.3i; IEEE 802.3u; IEEE 802.3ab ; IEEE 802.3x Interface- 24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) Network Media- 10BASE-T UTP category 3; 4; 5 cable (maximum 100m) 100BASE-TX/1000BASE-T UTP category 5; 5e or above cable (maximum 100m) |
Fan Quantity | Fanless |
Physical Security Lock | No |
Power Supply | 100-240VAC; 50/60Hz |
Power Consumption | Maximum |
Mounting | Rack Mountable |
Max Power Consumption | 13.62W(220V/50Hz) |
Max Heat Dissipation | 46.44BTU/h |
PERFORMANCE | Switching Capacity -48Gbps Packet Forwarding Rate -35.7Mpps MAC Address Table- 8K Jumbo Frame -10KB Green Technology -Yes Transfer Method- Store-and-Forward |
OTHERS | Certification- FCC; RoHS Package Contents- 24-Port Gigabit Desktop/Rackmount Switch Power Cord Installation Guide Rackmount Kits Rubber Feet |
Package Dimension (W, H, L ) in cm | 18 x 4.4 x 29.4 |
Warranty | 1 Year Warranty |
