| Image Sensor |
8.29 megapixel progressive scan CMOS |
| Max. Resolution |
3840 (H) × 2160 (V) |
| Min. Illumination |
Color: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
PAL: 1/12.5 s to 1/50,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360° |
| Signal System |
PAL/NTSC |
| Lens Type |
2.8 mm, 3.6 mm, 6 mm fixed lens |
| Focal Length & FOV |
102.2° (2.8 mm), 79° (3.6 mm), 50.8° (6 mm) |
| Lens Mount |
M16 |
| Image Settings |
Brightness, Sharpness, DNR, Smart IR, HLC |
| Frame Rate |
TVI: 8MP@12.5fps, 8MP@15fps, 4MP@25fps, 4MP@30fps,2MP@25fps, 2MP@30fps |
| Day/Night Mode |
Auto/Color/BW (Black and White) |
| Wide Dynamic Range (WDR) |
Digital WDR/ 105 dB |
| Image Enhancement |
BLC |
| White Balance |
Auto/Manual |
| Video Output |
1 HD analog output,TVI/AHD/CVI/CVBS |
| Material |
Plastic |
| Dimension |
58 mm × 61 mm × 159.8 mm (2.28" × 2.40" × 6.42") |
| Weight |
Approx. 210 g (0.46 lb.) |
| Language |
English |
| IR Range |
Up to 30 m |
| Consumption |
Max. 5.3 W |
| Protection |
IP67 |
