Print Parameter | |
Printing Method | Thermal Line |
Effective Printing Width | 48mm |
Resolution | 384 dots/line(8dots/mm,203dpi) |
Printing Speed | 70mm/S |
Interface | USB (Default), Serial, Bluetooth (Optional) |
Line spacing | 3.75mm( Can adjust line spacing by command) |
Line No. | Font A:32 character /Line, Font B:42 character/Line, Simple/Traditional Chinese-16 lines |
Character | The standard GB18030 simplified / traditional Chinese characters library |
Character Size | ANK character,Font A:1.5×3.0 mm(12×24 dots, Font B:1.1×2.1mm(9×17 dots, Simplified/Traditional:3.0×3.0mm(24×24 dots) |
Barcode Character | |
Extended character set | PC437/Katakana/PC850/PC860/PC863/PC865/ WestEurope/Greek/Hebrew/EastEurope/Iran/ WPC1252/PC866/PC852/PC858/IranII/Latvian/ Arabic/PT151,1251/PC737/WPC/1257/ ThaiVietnam/PC864/PC1001/(Latvian)/ (PC1001)/(PT151,1251)/(WPC1257)/ (PC864)/ (Vietnam)/(Thai) |
Barcode | 1D Bar code:UPC-A/UPC- E/JAN13(EAN13)/ JAN8(EAN8)CODE39/ITF/ CODABAR/ CODE93/CODE128 2D.Bar code:QRCODE |
Graphics Printing | |
Graphics printing | Supports bitmap download and print (support each bitmap size Max.8K, download up to 5pcs) |
Power saving Mode | |
Smart power saving | Support |
Variable speed printing | Support |
Consumption | Support |
Dormancy | Support |
Dection | |
Sensor | Lack of paper detection |
Indicator | |
Power Display | Support |
Charge Indicator | Support |
Lack of paper | Support |
Beep | Lack of paper, printing abnormal alarm |
Paper | |
Type | Thermal |
Width | 57.5±0.5mm |
thickness | ≤0.12mm |
Diameter | ≤40mm |
Feed | Easy(Clameshell feed |
Commands | |
Commands | ESC/POS |
Power | |
Charger | 9.0V/2A |
Buffer | |
Input | 4KB |
NV Flash | 40KB |
Physical Features | |
Weight | 224g |
Dimension | 114*80*50mm |
Environment | |
Operating | Temp:5 ~ 45℃, Humidity:10 ~ 80% |
Storage | Temp:-10 ~ 50℃ ,Humidity:10 ~ 90%(No Dew) |
Reliability | |
Print head life | 50KM(Printing Density≤12.5) |
