XPG CORE REACTOR II 750W ATX 3.0 - 80 Plus Gold Full Modular Power Supply - Black

The XPG CORE REACTOR II delivers reliable power for high-performance gaming and workstation builds. This 750W fully modular power supply features 80 Plus Gold efficiency, ensuring minimal energy waste and lower electricity costs. ATX 3.0 compatibility supports next-generation graphics cards and components. The modular cable design reduces clutter inside your case for improved airflow and easier cable management. Built with premium components for stable, consistent power delivery across all your system's demanding loads.

The XPG CORE REACTOR II GOLD power supply series offers highly efficient power conversion. These units score on the higher side of 80 PLUS Gold efficiency ratings, nearly reaching Platinum performance levels; delivering an outstanding efficiency performance of up to 89% at 20% load, 90.91% at 50% load, and 88% at 100% operating load. The CORE REACTOR II is an ideal choice for users who require both Gold efficiency and a well-designed fan curve. It’s capable of supporting mid to high-end graphics cards and the latest processors. Depending on the wattage level you need, CORE REACTOR II comes in a variety of dimensions, available in both black and white. With five wattage options (650W, 750W, 850W, 1000W, 1200W), there is a perfect unit for every system.

Key Features:

• GOLD certified by both 80 PLUS and Cybenetics.
• built with Premium Grade 100% Japanese
• Compliant with a 12VHPWR (12+4) Connector.
• Compliant with Intel ATX 3.0 and PCIe 5.0.

Specifications

• Type : Intel ATX 12V v3.0
• Maximum Power : 750 W
• Fans : 1 x 120 mm
• PFC : 0.99
• Main Connector : 20+4Pin
• +12V Rails : Single
• PCI-Express Connector : 1 x 12VHPWR 12+4Pin, 4 x PCI-E 6+2 to 6+2 Pin, 2 x PCI-E 6+2 Pin
• SATA Power Connector : 8
• Max PSU Length : 150 mm
• Modular : Full Modular
• Energy-Efficient : 80 PLUS GOLD Certified
• Over Voltage Protection : Yes
• Input Voltage : 100 - 240 V
• Input Frequency Range : 47 - 63 Hz
• Input Current : 10A
• Output : +3.3V@22A,+5V@22A, +12V@62.5A, -12V@0.3A, +5VSB@3A
• MTBF : 100,000 hours @ 25°C
• Approvals : CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Mark | NOM | BSMI | UKCA |EAC | CCC | RCM
• CORE REACTOR II series power supply units meet Intel ATX 3.0 design guide specifications and feature a 12VHPWR connector. By upgrading to an ATX 3.0 compliant power supply, you'll be fully equipped for the upcoming wave of new high-performance components. A must for the modern gamer, creator, or AI developer. Stay ahead of the curve by upgrading to an ATX 3.0 PSU, the new standard in PC hardware.
• Dimension & Weight
• Dimensions : 140 x 150 x 85mm
• Weight : 1.59kg
